D Series Paint Protection Film
Generate QR code
-
Estimated Delivery:Jun 30 - Jul 04
-
Free Shipping & Returns: On all orders over $75
Product description
Shipping & Return
Product Parameters
Paint Protection Film Series Parameters
D1, D3, D5 and D7 paint protection film series are available for different vehicle protection needs, covering standard protection, hydrophobic protection and enhanced thick TPU protection.
D1
D1 Series Paint Protection Film
Entry Series
- Thickness6.5±0.2mil
- Tensile Strength23.9MPa
- Elongation at Break240%
- Max. Operating Temp.116°C
- Warranty5 Years
D3
D3 Series Paint Protection Film
Balanced Series
- Thickness7.5±0.2mil
- Tensile Strength29.4MPa
- Elongation at Break260%
- Max. Operating Temp.116°C
- Warranty5 Years
D3 Hydrophobic
D3 Hydrophobic Paint Protection Film
Hydrophobic
- Thickness7.5±0.2mil
- Tensile Strength28.4MPa
- Elongation at Break265%
- Hydrophobic Angle≥103°
- Warranty5 Years
D5
D5 Series Paint Protection Film
Enhanced Series
- Thickness8.5±0.2mil
- Tensile Strength29.7MPa
- Elongation at Break265%
- Max. Operating Temp.116°C
- Warranty5 Years
D5 Hydrophobic
D5 Hydrophobic Paint Protection Film
Hydrophobic
- Thickness8.5±0.2mil
- Tensile Strength29.6MPa
- Elongation at Break285%
- Hydrophobic Angle≥103°
- Warranty5 Years
D7
D7 Series Paint Protection Film
Premium Series
- Thickness9.5±0.2mil
- Tensile Strength31.4MPa
- Elongation at Break280%
- Max. Operating Temp.116°C
- Warranty5 Years
Parameter Comparison
| Item | D1 | D3 | D3 Hydrophobic | D5 | D5 Hydrophobic | D7 |
|---|---|---|---|---|---|---|
| Thickness | 6.5±0.2mil | 7.5±0.2mil | 7.5±0.2mil | 8.5±0.2mil | 8.5±0.2mil | 9.5±0.2mil |
| Tensile Strength | 23.9MPa | 29.4MPa | 28.4MPa | 29.7MPa | 29.6MPa | 31.4MPa |
| Elongation at Break | 240% | 260% | 265% | 265% | 285% | 280% |
| Max. Operating Temperature | 116°C | 116°C | — | 116°C | — | 116°C |
| Hydrophobic Angle | — | — | ≥103° | — | ≥103° | — |
| Heat Self-Healing | Minor scratches can self-heal with 60°C hot water. | |||||
| Stain Resistance | Marker stains can be wiped off with alcohol without leaving marks. | |||||
| Chemical Resistance | No damage after 30 seconds of carburetor cleaner immersion. | |||||
| Aging Resistance | No damage after QUV 1000h aging test. | |||||
| Warranty | 5 Years | |||||
Note: The above parameters are organized from product images and can be used for product detail pages, series comparison and customer selection reference.
Shipping cost is based on weight. Just add products to your cart and use the Shipping Calculator to see the shipping price.We want you to be 100% satisfied with your purchase. Items can be returned or exchanged within 30 days of delivery.
